Specifications
Section 4: Specifications
4.1 Weight and Dimensions
Figure 4-1:Dimensions, Side View
Table 4-1:Weight and Dimensions Side View
Wheel base
1811 mm (71.3 in)
Length
2588 mm (101.89 in)
Height, with ROPS
2649 mm (104.3 in)
Height, without ROPS
1836 mm (72.3 in)
Thickness
13 mm (0.5 in)
Weight Standard equipped roller
3000 kg (6613.87 lbs)
