The emergency button is used to stop the
in an emergency situation which it cannot be
shut
off in an usual manner. It switches off the engine
Figure 5-7:Sprinkler Switch1
and activates the brakes. The emergency stop
aborts the entire control operation in a quicker
way for the safety of the personnel.
Figure 5-5: Emergency Stop
A Emergency stop button
A
A
Upper position
B
Intermediate position
B
C Lower position
C
Forward/Neutral (FNR)
Lever
Direction of travel and speed of the roller is
regulated with the forward/reverse lever. The
machine speed increases or decreases in
proportion to the position of the lever.
Figure 5-6: FNR Lever
A FNR lever
Figure 5-8:Sprinkler Switch2
Press AUTO for variable adjustment of the water
flow from 0 to100%.
Seat Buzzer
Seat buzzer beeps if the operator is not seated
during the operation of the roller and it continues
to beep until the operator is seated. If the buzzer
beeps for long the brakes are activated and
engine is forced to stop.
Upper position
Switches on the flow of water
to drum.
Intermediate
position
Switches off the sprinkle.
Lower position
Switches on the flow of water
to drums by using forward or
reverse lever. The flow of water
is controlled by setting the
sprinkler timer.
