DYNISCO UPR800 Series Instruction Manual
Page | 12
Sensor Type and Range:
Thermocouple J -200/+800°C -328/+1472°F
Thermocouple K -200/+1200°C -328/+2192°F
Thermocouple L -200/+800°C -328/+1472°F
Thermocouple N 0/1300°C 32/+2372°F
Thermocouple T -200/+400°C -328/+752°F
Thermocouple E -200/+600°C -328/+1112°F
RTD Pt100 -200/+600°C -328/+1112°F
RTD Pt500 -200/+600°C -328/+1112°F
Input Protection: Open circuit detection for strain gage (on signal and excitation wires),
thermocouple, RTD and 4-20mA inputs; not available for 0-10Vdc, 0-5Vdc and 0-20mA
inputs. Up or down scale keyboard.
Input Impedance:
>1MK for thermocouple input.
<10K for linear current input
>165KK for linear voltage input
T/C Lead Length: 100K max.
Reference Junction Compensation: from -20 to 60°C.
RTD measure system: 3 wire.
RTD Lead Length Compensation: Up to 20K/wire for the Pt100 and Pt500.
Sampling Time: Temperature input is selectable among 100, 200, 500 or 1000mS;
differential pressure is 50 mS, typical.
Display Update: At each sample.
Input Resolution with Linear Input: 4000 counts.
Low/High Scale Values: From -1000 to 3000, linear inputs only. Secondary differential
pressure is selectable, but with the same resolution and decimal point position of the
primary pressure input.
Decimal point: Settable in any position.
NOTE: These secondary inputs are not isolated from the primary input. A double or
reinforced insulation between instrument output and power supply must be guaranteed by
the external device.
