DYNISCO UPR800 Series Instruction Manual
Page | 22
6.1 Terminal Assignments
Terminal
Terminal
Assignment -
Description
Function
category / class
Voltage
Rating,
V
Current
Rating,
A
Load type and Rating
1 RTD, T/C +
Secondary Inputs
CAT I
2 Vdc 0.001 Adc
3 RTD, T/C -, mA/V -
4 mA +, RTD compensation 0.020 Adc
5 V + 10 Vdc
6 SIG +
Secondary Input Strain
Gage
CAT I
From 340N to 5000N,
Excitation 10Vdc ±7% (between
EXC + and EXC -)
7 SIG -
8 CAL2
10 EXC +
11 EXC - , CAL1
12 SIG +
Main Input Strain Gage
CAT I
From 340N to 5000N,
Excitation 10Vdc ±7% (between
EXC + and EXC -)
13 SIG -
14 CAL2
16 EXC +
17 EXC - , CAL1, mA -, V -
18 mA +
Main Linear Inputs
CAT I
0.020 Adc
19 V + 10 Vdc
21 OUT1 mA/V +
Main Analog
Retransmission
Class 2
±12.5 Vdc min load 5KN.
-5/+25 mA max load 500N
(max. load 400K over 20 mA).
22 OUT1 mA/V -
23
RESET
Remote Reset of Alarm
and/or peak
Class 2
Dry Contact switch
(voltage free)
24
29 SHIELD
Standard ProfiBus
Communication
Class 2
30 5VP
31 B/B’
32 A/A’
33 DGND
45 ALARM1 N.O.
Relay contacts used to
identify an event (alarm)
condition
240 Vac, 2A , resistive
46 ALARM1 C
47 ALARM1 N.C
48 ALARM2 N.O.
49 ALARM2 C
50 ALARM2 N.C.
51 ALARM3 C
52 ALARM3 N.C./N.O.
53
Line ~ or +
Main Power Supply
(according to the Product Code)
100 – 240Vac
27VA maximum
or
24Vdc, 12W maximum
24Vac, 18VA maximum
Class 2
54
Neutral
~ or -
55 Earth (Ground)
56 OUT2 mA/V +
Secondary Analog
Retransmission
Class 2
±12.5Vdc min load 5KN.
-5/+25 mA max load 500N
(max. load 400K over 20 mA).
57 OUT2 mA/V -
58 Vdc SUPPLY +
Auxiliary Power Supply
Class 2
24 Vdc
0.063 Adc
(1.5W)
59 Vdc SUPPLY -
60 A/A’
Serial Communication
RS485
Class 2
61 B/B’
62 C
Note:
The instrument is not suitable for use with equipment for measurement within measurement categories II, III and IV.
