DYNISCO UPR800 Series Instruction Manual
Page | 15
Type of Output Function: Keyboard selectable as
• Primary input retransmission
• Secondary input retransmission
Type of Analog Output: Keyboard selectable between:
• +0/10Vdc min. load 5 KN, with under/over range capability from -2.5 to 12.5V
• -10/+10Vdc mm. load 5KN, with under/overrange capability from -12.5 to 12.5V
• +0/5Vdc mm. load 5KN, with under/overrange capability from -1.25 to 6.25V
• +0/20mA max. load 500N, with under/over range capability from -5 to 25mA
(max. load 400N over 20mA).
• +4/20mA max. load 500N, with under / over range capability from 0 to 24mA
(max. load 400N over 20mA).
2.11 Second Analog Output Specification
Second Analog Output: Opto-isolated from CPU input and output circuits.
Type of Output Function: Keyboard selectable for:
• Primary input retransmission
• Secondary input retransmission
Type of Analog Output: Keyboard selectable between:
• +0/10Vdc min. load 5KN, with under/over range capability from -2.5 to 12.5V
• +0/5Vdc min. load 5 KN, with under/over range capability from -1.25 to 6.25V
• +0/20mA max. load 500N, with under/over range capability from 0 to 24mA
(max. load 400N over 20mA).
• +4/20mA max. load 500N, with under/over range capability from 0 to 24mA
(max. load 400N over 20mA).
2.12 Primary & Secondary Analog Outputs Common Specification
Resolution: 0.1% of output span.
Reference Accuracy: ±0.1% of output span @ 25 ± 1°C and nominal line voltage.
Linearity Error: <0.1% of output span.
Output Noise: <0.1% of output span.
Scaling: The retransmission low and high limits are selectable from 0 to primary input
full-scale value (when the retransmitted variable is primary input) or from low to high
secondary limits (when the retransmitted variable is the secondary input). The two scaling
values may be freely selectable within the above range. This allows having a direct or
reverse output type.
Output Filter: Selectable: OFF, 0.4S, 1S, 2S, 3S, 4S, 5S
