DYNISCO UPR800 Series Instruction Manual
Page | 19
5.0 HARDWARE
The UPR800 is shipped configured for the following:
• Primary Input (Pressure) - Strain Gage
• Optional Secondary Input - Thermocouple
• Main Output - Voltage
• Optional Secondary Output – Voltage
• Security lock is OFF
Please refer to the drawings in the appropriate sections to determine the configuration for
input(s) and output(s) used in your particular application. It is necessary only to select the
category (e.g. Voltage or Current). The specific range will be chosen in the software
menu.
