DYNISCO UPR800 Series Instruction Manual
Page | 75
Range: 50, 60, und.60
50, 60: when the device is able to detect correctly 50 or 60 Hz line
frequency. und.60: automatic detection of the line frequency doesn’t
work (e.g. 24V DC power supply); a 60 Hz rejection is assumed.
Default value: Not applicable.
LOADING DEFAULT DATA - Group 4
Available: Only if access to level C is allowed
Upper display: OFF
Lower display: DEFLT
Range: Use u t keys to switch the upper display from OFF to On 4, then
press FUNC key to load the default data of the parameters belonging
to group 1, group 2, group 3 and group 4
12.5 Group 5 Parameters
PRIMARY INPUT SELECTION - Group 5
Available: Always
Upper display: Type of primary input selection
Lower display: PI.TYP
Range: Str, 0-20, 4-20, 0-5, 0-10. Strain gage, 0-20mA, 4-20mA, 0-5V, 0-10V
Default value: Strain gage
Note: Proper terminal block wiring required
SECONDARY INPUT SELECTION - Group 5
Available: Only is secondary input circuit is fitted
Upper display: Type of secondary input selection
Lower display: SI.TYP
Range: OFF, tc, rtd, 0-20, 4-20, 0-10. Disabled thermocouple, RTD, 0-20
mA, 4-20mA, 0-10V
Default value: Thermocouple
Note: Proper terminal block wiring required
SECONDARY INPUT FUNCTION - Group 5
Available: Only if SI.TYP is different from OFF.
Alterable: Only if SI.TYP is equal to 0-20, 4-20, 0-5, 0-10; otherwise it is forced
according to the SI.TYP value.
Upper display: Function of secondary input.
Lower display: SI.FNC
Range: tenp, diff.P., where tenp input acts as a temperature input and diff.P
input acts as the second sensor for differential pressure
measurement
Default value: tenp.
MAIN ANALOG OUTPUT SELECTION - Group 5
Available: Always
Upper display: Type of main analog output selection
Lower display: MO.TYP
