DYNISCO UPR800 Series Instruction Manual
Page | 41
8.6.1 Setting the Main Analog Output Type
The Main Analog Output Type sets the output to specific voltages or currents. The
available outputs are 0-20mA, 4-20mA, 0-10Vdc, -10 to +10Vdc, and 0-5Vdc. To change
or view this value, press the FUNC key until nonE and GROUP show on the display.
Press the t key until 5 shows in the upper display. Press the FUNC key until the lower
display changes to MO.TYP, and the upper display shows the selected type. Press
the u or t keys until the upper display changes to the desired value. Then press the
FUNC key to lock in the value and advance to the next parameter, or press RESET to
return to the operating screen. Similarly if the unit has a Secondary input, the Secondary
Analog Output Type (SO.TYP) can be set in the same manner.
8.6.2 Setting the Main Analog Output Link
To change or view this value, press the FUNC key until nonE and GROUP show on the
display. Press the t key until 3 shows in the upper display. Press the FUNC key until
the lower display changes to MO.LNK, and the upper display shows the selected type,
either PrI.In (the primary input) or SEc.In (the secondary Input). Press the u or t keys
until the upper display changes to the desired value. Then press the FUNC key to lock in
the value and advance to the next parameter, or press RESET to return to the operating
screen. Similarly the Secondary Analog Output Link (SO.LNK) can be set in the same
manner.
8.6.3 Setting the Main Analog Output Range Low
To change or view the Main Analog Output Range Low, press the FUNC key until nonE
and GROUP show on the display. Press the t key until 3 shows in the upper display.
Press the FUNC key until the lower display changes to MO.LO. Press the u or t keys
until the upper display changes to the desired value. The value may be anything from 0
to the primary input full scale value, PI.FSV if the MO.LNK is set to PrL.Ln, or if the
MO.LNK is set to SEc.Ln, the value may be from –1000 to 3000. Once the desired value
is set, press the FUNC key to lock in the value and advance to the next parameter, or
press RESET to return to the operating screen. Similarly the Secondary Analog Output
Range Low (SO.LO) can be set in the same manner.
8.6.4 Setting the Main Analog Output Range High
To change or view the Main Analog Output Range High, press the FUNC key until nonE
and GROUP show on the display. Press the t key until 3 shows in the upper display.
Press the FUNC key until the lower display changes to MO.HI. Press the u or t keys
until the upper display changes to the desired value. The value may be anything from 0
to the primary input full scale value, PI.FSV if the MO.LNK is set to PrL.Ln, or if the
MO.LNK is set to SEc.Ln, the value may be from –1000 to 3000. Once the desired value
is set, press the FUNC key to lock in the value and advance to the next parameter, or
press RESET to return to the operating screen. Similarly the Secondary Analog Output
Range High (SO.HI) can be set in the same manner.
8.6.5 Setting the Main Analog Output Filter
Filtering is an electrical method of averaging the output values over a period of time to
arrive at a smoother curve. This helps to eliminate short duration transients and spikes
that may cause false or spurious readings.
