DYNISCO UPR800 Series Instruction Manual
Page | 6
Wiring
Connect the wires from transducer cable as shown in the terminal diagram,
turn the screws with a torque between 1.0 and 1.2 Nm.
Connect an appropriate length of thermocouple extension wire (Type J) to the
connector.
Connect the thermocouple to the appropriate terminals (remember that red is
negative).
Connect alarm(s) if applicable. Note that alarm defaults are High, Reverse
Acting.
Connect power to the appropriate terminals as shown.
Scaling
Apply power to the instrument; Upper display will give a reading near zero.
Lower display will read the actual temperature.
Press FUNC key until the Upper display reads NONE.
Lower display reads GROUP.
If your transducer is not a 10,000-psi model, select Group 3 using the Up
arrow, enter with function key.
Lower display reads PI.FSV (Full Scale Value), and the upper display reads
10,000. Note: If your transducer is a 10,000 psi model skip next two steps.
Scroll to GROUP.
Using the Down arrow key set the appropriate Full Scale Value for your
transducer.
Enter using the FUNC key to scroll until GROUP legend appears again.
Using Up arrow key, select GROUP 2.
Calibration and Operation
Lower display reads ZERO.C and upper display reads OFF. Be sure
transducer is at operation temperature and that no pressure is
applied.
Change upper display to ON by using the Up arrow key. Enter with
the FUNC key. After a few seconds, the lower display will show
SPAN.C and upper display will show OFF.
Change upper display to ON using Up arrow key. Enter with the
FUNC key. In a few seconds lower display shows DSP.FL and
upper display shows 0.4. Calibration is complete.
Using the FUNC key, scroll to the GROUP display. Enter 1 with the
Up arrow, and enter with the FUNC key. Instrument shows 0 (±10)
on upper display and temperature on lower display. System is ready
for use.
References to Profibus features and instructions should be ignored. Profibus is being
considered for a future line expansion and has been accommodated in the current design.
