DYNISCO UPR800 Series Instruction Manual
Page | 36
8.3.6 Setting the Primary Input Decimal Place
To set the decimal place, press the FUNC key until nonE and GROUP show on the
display. Press the t key until 3 shows in the upper display. Press the FUNC key until
the lower display shows PI.DP. Press the u or t key until the upper display shows the
correct decimal place location. Press the FUNC key to set the value. Finally, press the
RESET key to go back to the active display.
8.3.7 Setting the Primary Input Failsafe Mode
The Primary Input Failsafe Mode is nothing more than a safety mechanism that tells the
instrument what to do in the event of a loss of the primary signal. If the system is set up
to shut down the process in a high alarm condition, the Primary Input Failsafe parameter
sets the value of the primary input to full scale if it loses the primary signal. If the system
is set up to shut down the process in a low alarm condition, the Primary Input Failsafe
parameter sets the value of the primary input to low scale if it loses the primary signal.
The default Primary Input Failsafe Mode is to set the value to full scale high.
To set the Primary Input Failsafe Mode, press the FUNC key until nonE and GROUP
show on the display. Press the t key until 4 shows in the upper display. Press the
FUNC key until the lower display shows PI.IFS. Press the u or t key until the upper
display shows the correct mode, either HI or Lo. Press the FUNC key to set the value.
Finally, press the RESET key to go back to the active display.
8.4 Secondary Input Setup
Skip this section if there is no secondary input or if this is a new installation and the
secondary input is for a “J” type thermocouple expressed in degrees Fahrenheit (°F).
8.4.1 Setting the Secondary Input Type
The Secondary Input measured values will show in the lower display. The Instrument’s
default secondary input setting is for a “J” type thermocouple. To select another type of
input, press the FUNC key until nonE and GROUP show on the display. Press the t key
until 5 shows in the upper display. Press the FUNC key twice and the upper display will
show tr while the lower display shows SI.TYP. Press the u or t key until the upper
display changes to the correct value (rtd for Platinum RTD, 0-20 for 0-20 mA linear input,
4-20 for 4-20mA current loop input, 0-10 for 0-10Vdc linear input, and OFF if the input is
to be disabled. Press the FUNC key to set the value. Finally, press the RESET key to go
back to the active display.
Remember to change software configuration to correspond to the proper input.
8.4.2 Setting the Secondary Input Scale and Decimal Point
Skip to “Setting the Thermocouple Type and Units” if the secondary input is for an RTD or
a thermocouple.
If the Instrument’s secondary input is set as a voltage or current, the Range Values need
to be set. Press the FUNC key until nonE and GROUP show on the display. Press the
t key until 3 shows in the upper display. Press the FUNC key and the upper display will
show the full scale value while the lower display shows SI.FSV. Press the FUNC key until
