DYNISCO UPR800 Series Instruction Manual
Page | 71
SECOND ANALOG OUTPUT RANGE HIGH - Group 3
Available: Only if SO.TYP is different than OFF.
Upper display: Range high for second analog output.
Lower display: SO.HI
Range: from 0 to PI.FSV (if SO.LNK = PrI.In) from -1000 to 3000 (if SO.LNK -
SEc.In).
Default value: PI.FSV.
SERIAL COMMUNICATION INTERFACE ADDRESS - Group 3
Available: Only if serial communication interface is fitted.
Upper display: Serial communication interface address
Lower display: SC.ADR
Range: OFF, 1, 2, …, 255. Off disables serial interface
Default value: Off
PROTOCOL TYPE - Group 3
Available: Only if SC.ADR is different than off
Upper display: Protocol type
Lower display: SC.BUS
Range: nodbS, JbuS. Modbus/Jbus selection
Default value: Modbus
COMMUNICATION TYPE - Group 3
Available: Only if SC.ADR is different than Off
Upper display: Number of bits
Lower display: SC.FRM
Range: 8, 8 E, 8 O. 8 bit without parity, 8 bit + even parity, 8 bit + odd parity
Default value: 8 bit without parity
COMMUNICATION BAUD RATE - Group 3
Available: Only if SC.ADR is different than Off
Upper display: Baud rate
Lower display: SC.BDR
Range: 600, 1200, 2400, 4800, 9600, 19200
Default value: 19200
LOADING DEFAULT DATA - Group 3
Available: Only if access to level 3 is allowed
Upper display: OFF
Lower display: DEFLT
Range: Use u t keys to switch the upper display from OFF to On 3, then
press FUNC key to load the default data of the parameters belonging
to group 1, group 2, group 3
