DYNISCO UPR800 Series Instruction Manual
Page | 72
SHUNT CALIBRATION - Group 4
Available: Always
Upper display: OFF if shunt calibration is disabled, On if shunt calibration is enabled
Lower display: SHUNT
Range: OFF, On
Default value: On
SHUNT VALUE - Group 4
Available: Only if SHUNT parameter is on
Upper display: Shunt value
Lower display: SHNT.%
Range: From 40.0 to 100.0%
Default value: 80.0%
PRIMARY INPUT FAIL SAFE - Group 4
Available: Always
Upper display: Primary input fail safe condition
Lower display: PI.IFS
Range: HI, LO
Default value: High
SECONDARY INPUT FAIL SAFE - Group 4
Available: Only if SI.TYP is different than OFF
Upper display: Secondary input fail safe condition
Lower display: SI.IFS
Range: HI, LO
Default value: High
ALARM 1 HYSTERESIS - Group 4
Available: Only if A1.LNK is different than OFF
Upper display: Alarm 1 hysteresis
Lower display: A1.HYS
Range: From 0.1 to 10.0% of the selected range
Default value: 1.0%
ALARM 1 RESET MODE - Group 4
Available: Only if A1.LNK is different than OFF
Upper display: Selected reset mode for alarm 1
Lower display: A1.RES
Range: Auto, LAtCh. Automatic reset, manual reset
Default value: Auto
ALARM 1 FAILSAFE MODE - Group 4
Available: Only if A1.LNK is different than OFF
Upper display: Selected failsafe mode for alarm 1
Lower display: A1.FSM
Range: FS, nFS. Failsafe mode, non-failsafe mode
