DYNISCO UPR800 Series Instruction Manual
Page | 54
Notes for Calibration Parameter Summary:
(1) Use the u or t keys to show to following functions:
CAL
IBRATION PARAMETERS SUMMARY
PARAMETER
CIRCUIT
INPUT TYPE
RANGE
VALUE
NOTE
PL.020 Primary Input Current Zero 0mA
PH.020 Primary Input Current Full scale 20mA
P.020 Primary Input Current Verify (2)
PL.05 Primary Input Voltage 0-5V Zero 0V
PH.05 Primary Input Voltage 0-5V Full scale 5V
P.05 Primary Input Voltage 0-5V Verify (2)
PL.010 Primary Input Voltage 0-10V Zero 0V
PH.010 Primary Input Voltage 0-10V Full scale 10V
P.010 Primary Input Voltage 0-10V Verify (2)
SL.020 Secondary Input Current Zero 0mA
SH.020 Secondary Input Current Full scale 20mA
S.020 Secondary Input Current Verify (2)
SL.05 Secondary Input Voltage Zero
SH.05 Secondary Input Voltage Full scale
S.05 Secondary Input Voltage Verify (2)
SL.010 Secondary Input Voltage Zero 0V
SH.010 Secondary Input Voltage Full scale 10V
S.010 Secondary Input Voltage Verify (2)
SL.TC Secondary Input Thermocouple Zero 0mV
SH.TC Secondary Input Thermocouple Full scale 50mV
S.TC Secondary Input Thermocouple Verify (2)
S*RJ Secondary Input Thermocouple Ref. junct.
Ambient
S.RJ Secondary Input Thermocouple Verify
Ambient
SL.RTD Secondary Input RTD100 Zero 0K (2)
SH.RTD Secondary Input RTD100 Full scale 320K
S.RTD Secondary Input RTD100 Verify (2)
SL.PT5 Secondary Input RTD500 Zero 0K
SH.PT5 Secondary Input RTD500 Full scale 1600K
S.PT5 Secondary Input RTD500 Verify (2)
ML.CUR Main analog output Current Zero -5 mA
MH.CUR Main analog output Current Full Scale 25 mA
M.CUR Main analog output Current Verify (3)
ML.VOL Main analog output Voltage Zero -12.5V
MH.VOL Main analog output Voltage Full scale 12.5V
M.VOL Main analog output Voltage Verify (3)
SL.CUR Second analog output Current Zero -5 mA
SH.CUR Second analog output Current Full scale 25 mA
S.CUR Second analog output Current Verify (3)
SL.VOL Second analog output Voltage Zero -12.5V
SH.VOL Second analog output Voltage Full scale 12.5V
S.VOL Second analog output Voltage Verify (3)
DEFLT Load default calibration and
code
DO NOT ATTEMPT TO MODIFY UNDER ANY
CIRCUMSTANCES
