304 E-MU Systems
Preset Programming
Editing Presets
6. Advance to the Filter Envelope parameter page.
7. Move the cursor underneath the time field and change the value to
about +50. Now when you press a key the filter slowly sweeps up.
8. Change the attack rate and note the change in the sound.
9. Set the envelope parameters as shown in the following table.
With the above setup, the filter sweeps up, then Decays back down to
the Decay 2 Level until you release the key. Then it sweeps down at the
Release rates. Play with the envelope parameters for awhile to get a feel
for their function. (If you're having trouble understanding the Envelope
Generators, please refer to the Programming Basics section in this
manual.)
Envelope Phase Time Level %
Attack 1 40 65
Attack 2 65 100
Decay 1 80 85
Decay 2 25 50
Release 1 97 20
Release 2 73 0
L1
FILTER ENVELOPE
M
ode: time-based
L1
FILT ENV RATE LEVEL
Attack1 50 1
00%
L1
FILT ENV RATE LEVEL
Attack1 50 +88%
