232 E-MU Systems
Preset Edit Menu
Preset Effects
Common
Preset
Parameters
This section of the Preset Edit menu chapter describes parameters that
affect all layers in the preset.
Preset Effects MP-7 has two stereo effects processors. When playing presets one at a time,
the two processors can be programmed as part of the preset. The diagram
below shows how the effects are integrated into the signal path using a
parallel effects send/return model, similar to a mixing console.
Refer to the Effects chapter for additional information and instructions for
setting up both the Preset Effects and the Master Effects.
Effect
A
Sum
Sum
Main
Outs
Effect
B
FX Send Amount
FX Send Amount
Layers
Reverb, Delay
Chorus, Flange
Dry Signal
