28 E-MU Systems
Instant Gratification
Multi-Channel Arpeggiator
9. Let’s check out the pattern generator. Go back to the Mode screen and
set the mode to “Pattern”.
10. Now advance to the Pattern screen (shown below) and move the cursor
to the Pattern Number field (the second field from the left).
OO
OO
See the Arpeggiator
Chapter for detailed information
on creating Patterns.
11. Try the various patterns. There are 200 permanent factory patterns and
100 user locations to store the patterns you create. Each pattern can
have up to 32 notes.
Multi-Channel
Arpeggiator
MP-7 is totally unique in its ability to run up to 32 arpeggiators at once!
Even two or three patterns at once can create very complex sequences and
dynamic landscapes of sound.
Here’s one way to access this ultra-powerful feature. There is one arpeg-
giator for each MIDI channel. First you’ll assign three of the Trigger Keys to
MIDI channels 01A-03A. Next, you’ll assign arpeggiator presets to these
channels. Then you’ll become addicted to this new way of making music.
Program the Trigger Keys
1. Press the Controllers button, then turn the data entry control until the
screen shown below appears.
OO
OO
Make sure the “Trigger
Buttons Function” in the
Controllers menu is set to “Play
Note Events”.
2. Move the cursor until it is underneath the Latch field and turn Latch
mode On.
3. Move the cursor until it is underneath the Channel field (Ch) and set
the channel to 01A.
4. Move the cursor until it is underneath the Trigger field (T1) and
change the Trigger to T2 (trigger button 2).
5. Turn Latch On for trigger button 2 and set the channel to 02A.
6. Change the Trigger to T3 (trigger button 3).
7. Turn Latch On for trigger button 3 and set the channel to 03A.
Set up the Presets
8. Press the Preset View button (located beneath the LCD). The preset
select screen appears.
MASTER ARPEGGIATOR
Pattern 3
8
0
Inversions
C01A V127 P00 A:P MP-7
026
3
arp:Hollographik
