Proteus operation manual
117
Specifications
TECHNICAL SPECIFICATIONS
Audio Channels: 32
Audio Outputs: 6
Submix Inputs: 4
Max. Output Level: +4 dB into 600Ω
Output Impedance: 100Ω
MIDI: In, Out, Thru
Data Encoding: 16 bit Linear
Sample Playback Rate: 39kHz
Signal to Noise: >90 dB
Dynamic Range: >90 dB
Frequency Response: 20Hz-18kHz
THD +N: <.05%
IMD: <.05%
Power Requirements: 25 watts
Operating Temperature: 110°F Max.
Dimensions: H: 1.75" W: 19" L: 8.5"
Weight: Proteus/1 ............. 4lb, 7oz (2 Kg)
Proteus/1 Plus 2 . 4lb, 7oz (2 Kg)
Proteus/2 ............. 4lb, 7oz (2 Kg) or 4lb, 12.5 oz (2.173Kg)
Proteus/3 ............. 4lb, 7oz (2 Kg)
