Proteus operation manual
121
Preset Data Format
Preset data is transmitted and received using the following format: The
standard system exclusive header (described below) is followed by the
preset number (lsb, msb), a 14 bit word for each preset parameter (lsb,
msb) starting at parameter #0 and continuing upward, a one-byte check-
sum, and the end-of-exclusive byte (F7). The checksum is the modulo 128
sum of all the parameter value bytes; that is, all of the data bytes following
the preset number and before the checksum.
PRESET PARAMETERS
Parameter Number Parameter Name
0-11 preset name (12 ascii characters)
12-14 link 1-3
15-18 low key 0-3
19-22 high key 0-3
23 pri instrument
24 pri sample start offset
25 pri tuning (coarse)
26 pri tuning (fine)
27 pri volume
28 pri pan
29 pri delay
30 pri low key
31 pri high key
32 pri alt attack
33 pri alt hold
34 pri alt decay
35 pri alt sustain
36 pri alt release
37 pri alt envelope on
38 pri solo mode
39 pri chorus
40 pri reverse sound
41 sec instrument
42 sec sample start offset
43 sec tuning (coarse)
44 sec tuning (fine)
45 sec volume
46 sec pan
MIDI SPECIFICATIONS
MIDI Specifications
