EDIT MENU
52
Proteus operation manualLFO 1
LFO 1 - RATE, DELAY and VARIATION
This screen controls the rate, delay and variation of LFO 1.
■ LFO Rate: varies the LFO speed from 0.052 Hz to 25 Hz (000-127).
■ LFO Delay: sets the amount of time between hitting a key and the onset
of modulation. This can be used to simulate an effect often used by
acoustic instrument players, where the vibrato is brought in only after the
initial note pitch has been established. The delay range is variable from 0
to 13 seconds (000-127).
■ LFO Variation: sets the amount of random variation of an LFO each
time a key is pressed. This function is useful for ensemble effects, where
each note played has a slightly different modulation rate. The higher the
number, the greater the note to note variation in LFO rate. LFO variation
is variable from 000-127.
LFO1 RT DLY VAR
000 000 000
LFO 2 - SHAPE and AMOUNT
LFO 2 is functionally identical to LFO 1.
LFO 2 - RATE, DELAY and VARIATION
LFO 2 is functionally identical to LFO 1.
time
key
down
Delay
The LFO wave begins after the specified delay time has elapsed.
