PROGRAMMING BASICS
38 Proteus operation manualStereo Mix Outputs
STEREO MIX OUTPUTS
Proteus has three sets of polyphonic stereo outputs (Main, Sub 1, Sub 2).
The channels used by a particular preset may be directed to appear at any
one of these three stereo outputs. This feature is useful for signal process-
ing (EQ, reverb, etc.) of individual sounds prior to final mixdown.
By panning a preset completely left or right, it can be routed to a single
output jack.
Note: All presets will be automatically routed to the Main outputs unless
plugs are inserted into the Sub 1 or Sub 2 outputs.
Main
Sub 1
Sub 2
Preset
01
Preset
22
Preset
12
Preset
127
MIX
OUTPUT
Preset
18
Preset
120
L
R
L
R
L
R
etc.
Each preset can be routed to one (and only one) set of stereo outputs.
