23
Proteus operation manual
MASTER MENU
User Key Tuning
VIEWING ANGLE
This function allows you to change the viewing angle of the display so that
it may be easily read from either above or below. The angle is adjustable
from +7 to -8. Positive values will make the display easier to read when
viewed from above. Negative values make the display easier to read from
below.
VIEWING ANGLE
+7
DEMO SEQUENCE
Proteus contains a play-only sequencer in order to give you an idea of
what is possible using this amazing machine. Press the cursor switch to
move the cursor to the bottom line of the display. The Enter LED will
begin flashing. Press the Enter switch to start the sequence. The Enter
LED will be lit and the bottom line of the display will change to "Stop".
Pressing the Enter button again will stop the sequence.
DEMO SEQUENCE
Start Sequence
C-2 C-1 C0 C1 C2 C3 C4 C5 C6 C7 C8
= Standard 5 Octave Keyboard Range
Proteus Keyboard Range
MIDI
Key #
Key
Name
0 1224364860728496108120127
