96
Proteus operation manual
PROTEUS/2 INSTRUMENTS
12345678910 151617 3118
12 3 4 5
Harmonic
Octave
Frequency (log)
Level
OCTAVE-5 ODD
17
19
21
23
25
27
29
31
HARMONIC WAVEFORMS
72. Oct 1 (Sine)
73. Oct 2 All
74. Oct 3 All
75. Oct 4 All
76. Oct 5 All
77. Oct 6 All
78. Oct 7 All
79. Oct 2 Odd
80. Oct 3 Odd
81. Oct 4 Odd
82. Oct 5 Odd
83. Oct 6 Odd
84. Oct 7 Odd
85. Oct 2 Even
86. Oct 3 Even
87. Oct 4 Even
88. Oct 5 Even
89. Oct 6 Even
90. Oct 7 Even
91. Low Odds
92. Low Evens
93. Four Octaves
As an example, this chart shows the harmonics present in the Octave 5 Odd waveform.
These are the same waveforms that are in
the Proteus/1 and are very useful, either
to accent certain harmonics in the
sampled sounds, or combined with other
waveforms for synthesized and additive
timbres.
Proteus/2 Harmonic Waveforms
