EasyWay 210 - TECHNICAL DATA OF THE ACTUATOR; Dimensions and Use Restrictions; DISASSEMBLY AND DISPOSAL

1. TECHNICAL DATA OF THE ACTUATOR
24V one-way mechanical gear motor for swing gates, with mechanical limiters
Power supply voltage
Vac
230 50/60 Hz
Main power supply Max 230 Vac
W
230
Input current for Max 230 Vac line
A
1
Motor type
Vdc
24
Max motor power
W
60+60
Max motor current
A
2.5 + 2.5
Thrust
N
1500
Continuous operation time
Minutes
20
Max gate weight
Kg
300
Max gate leaf length
m
2.5
Lubrication
Type
Permanent lubrication
Sound pressure
dB
LpA-70
Protection class
IP
44
Operating temperature
°C
From -20 to +70
Motor dimensions
mm
750 X 85 H 102
Weight
Kg
4
1.1 Dimensions and use restrictions
The type of gate, height, shape of the leaf, and climate conditions limit device use. Installation should be carefully
planned, taking them into consideration.
