EasyWay 210 - Wiring and Connecting Procedures; Central Connections Overview

3.1 Wiring and connecting
- Carefully read the SAFETY INSTRUCTIONS AND WARNINGS and INSTALLATION RECOMMENDATIONS AND
WARNINGS before starting wiring and connections.
- The power source should be disconnected before any wiring and connections works.
3.2 Central connections
Terminals
Description (check the wiring diagram (section 3.3)
1
AERIAL: Standard aerial input. Use an RG58-50 ohm cable.
2
AERIAL: Aerial cable input.
6
COMMON COMMANDS: For the inputs: STOP - OPEN - CLOSE - STEP BY STEP - PHOTO.
6 - 7
STOP: Input normally closed. Defines the stopping sequence of the gate.
It may have safety devices connected to it, such as an emergency stop button.
When the command is dismissed, automatic closing is NOT performed - a new movement command must be issued.
Leave the jumper on if no device has been attached.
6 - 8
OPEN: Input normally open. Defines the opening sequence of the gate.
6 - 9
CLOSE: Input normally open. Defines the closing sequence of the gate.
PHOTO1: With OPTION 1 LED 4, the input becomes normally closed to connect a photocell which intervenes in
opening and closing.
6 - 10
STEP BY STEP: Input normally open. It defines the gate movement for the following sequences: FOUR-STEP
MODE: Open, Pause, Close, Pause. SEMI-AUTOMATIC MODE: Open, Stop, Close, Stop.
HOUSING ESTATE MODE: Opens (automatic closing with active pause time).
6 - 11
PHOTO: Normally closed input intended for photocells or safety devices. Does not intervene during the opening
sequence. It inverts movement during the closing sequence until the gate is fully open. Leave the jumper on if no
device has been attached.
12 - 13
RELAY CONTACT: RELAY CONTACT: Dry contact relay, max. 3A, default for connecting an open gate light. When
OPTION 2 is activated, LED 2 becomes the command for the additional light for 3 minutes.
14 - 16
ELECTRIC LOCK: 12 Vdc output connecting a 12 Vdc 15 VA electric lock. To activate it, select the function from the
options 1 menu LED 3.
15 - 16
FLASHING: Output 24V dc max. 25 W for connecting a flashing light.
16
+
30 Vdc OUTPUT: Used to power various devices, max 200mA.
17
-
N.Z. = Normally closed contact - N.O. - Normally open contact
PEDESTRIAN: This command only opens one leaf. It can be issued with a remote control or with the terminal panel.
This terminal is obtained by bridging the 8 OPEN terminals with the 9 CLOSE terminals, and this jumper then connects with
the 6 COMMON terminals through a switch. The PEDESTRIAN command issued from the terminal panel excludes the OPEN
and CLOSE commands.
Bottom of the control unit with connections
CONN-1
24 Vac: Transformer power supply input
CONN-2
AGECH-2 battery charger input
33 - 34
- / +
Motor 2, opens second during closing.
35 - 36
- / +
Motor 1, opens first during closing.
