Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0 21
Figure 9. 2-High EBM Cabinet Center of Gravity
Dimensions are in millimeters [inches]
Weight and Center of Gravity
Dimensions mm [in]
See Figure 9.
Weight
kg [lb]
A B C
Eaton 9155 Extended Battery
Module 2-High
81 [3.2] 452 [17.8] 406 [16.0] 218 [480]
UPS Installation Plan and Unpacking
