Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0 23
Figure 11. 3-High EBM Cabinet Center of Gravity
Dimensions are in millimeters [inches]
Weight and Center of Gravity
Dimensions mm [in]
See Figure 11.
Weight
kg [lb]
A B C
Eaton 9155 Extended Battery
Module 3-High
81 [3.2] 452 [17.8] 610 [24.0] 276 [609]
33..33 UUPPSS SSyysstteemm PPoowweerr WWiirriinngg PPrreeppaarraattiioonn
Read and understand the following notes while planning and performing the installation:
UPS Installation Plan and Unpacking
