Eaton 9155 UPS - Figure 33. Battery Panel (Dead Front)

Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0 47
Figure 33. Battery Panel (Dead Front)
Front View, Front Covers Removed
2-High Cabinet Shown
Battery Panel
(Dead Front)
Front View, Front Covers Removed
3-High Cabinet Shown
4. Connect the UPS battery wiring to the Battery tray wiring, red connector to red connector, black connector
to black connector (see Figure 34 and Figure 35).
UPS System Installation
