Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0 27
CChhaapptteerr 44 UUPPSS SSyysstteemm IInnssttaallllaattiioonn
44..11 PPrreelliimmiinnaarryy IInnssttaallllaattiioonn IInnffoorrmmaattiioonn
WARNING
Installation should be performed only by qualified personnel.
Refer to the following while installing the UPS system:
• Review Chapter 3 UPS Installation Plan and Unpacking, for cabinet dimensions, equipment weight,
wiring and terminal data, and installation notes.
• Do not tilt the cabinets more than ±10° during installation.
• Remove conduit landing plates to add conduit landing holes as required.
• If perforated floor tiles are required for ventilation, place them in front of the UPS.
44..22 UUnnllooaaddiinngg tthhee UUPPSS CCaabbiinneett ffrroomm tthhee PPaalllleett
The following tools are required for unloading the cabinet(s):
• 15 mm wrench or socket
• 7 mm nutdriver or socket
CAUTION
The UPS and Extended Battery Module (EBM) are heavy (see ). Unloading the cabinets requires at least two
people to safely remove the cabinets from the pallet.
To remove the UPS or EBM from the shipping pallet:
1. Remove the two M10 bolts securing the stabilizing bracket to the pallet (see Figure 12).
