EDR-5000 IM02602007E
Direct Commands
Parameter Description Setting range Default Menu path
ResFc all Resetting of all Statistic values (Current Demand, Power
Demand, Min, Max)
Inactive,
Active
Inactive [Operation
/Reset]
ResFc I Demand Resetting of Statistics - Current Demand (avg, peak avg) Inactive,
Active
Inactive [Operation
/Reset]
ResFc P Demand Resetting of Statistics - Power Demand (avg, peak avg) Inactive,
Active
Inactive [Operation
/Reset]
ResFc Min Resetting of all Minimum values Inactive,
Active
Inactive [Operation
/Reset]
ResFc Max Resetting of all Maximum values Inactive,
Active
Inactive [Operation
/Reset]
Global Protection Parameters of the Statistics Module
Parameter Description Setting range Default Menu path
ResFc Max Resetting of all Maximum values 1..n, Assignment
List
-.- [Device Para
/Statistics
/Min / Max]
ResFc Min Resetting of all Minimum values 1..n, Assignment
List
-.- [Device Para
/Statistics
/Min / Max]
Start I Demand via: Start Current demand by: Duration,
StartFct
Duration [Device Para
/Statistics
/Demand
/Current Demand]
www.eaton.com 174
