EDR-5000 IM02602007E
Slot X1: Power Supply Card with Digital Inputs
Rear side of the device (Slots)
The type of power supply card and the number of digital inputs on it used in this slot is dependent on the ordered device
type. The different variants have a different scope of functions.
Available assembly groups in this slot:
(DI8-X1): This assembly group comprises a wide-range power supply unit;
and two non-grouped digital inputs and six (6) digital inputs (grouped).
The available combinations can be gathered from the ordering code.
www.eaton.com 30
X1
X2
X3
X100 X102
X5 X6
X104
X4
X103
slot3 slot4 slot5 slot6slot1 slot2
X101
To Next Page
