Inactive
Active
IG.Dir n poss-
>Nondir Trip
1
2
Se tting Value:
<Name>.
I
Device Planning:
<Name>
Signal:
IG
Me asured Values:
<Name>.*int Alm L1
Internal messa ge
Functional description: If the setting
value "IE D ir n poss-> Nondir Trip" is
set to "inactive", the output 1 is active
and output 2 is inactive. If the setting
value "IE D ir n poss-> Nondir Trip" is
set to "active", the output 2 is active
and the output 1 is inactive.
Prot.I dir fwd
AR.t-D
0t-D
φ
"
φ
"=Elements with complex functions
"gray-box".
Inactive
Active
Bkr.Latched
Option/features to be realised in the future.
Pa rameter of a Module-Input with a
Se lectionList/DropDown. An (1..n)
signal/output from the list or a pre-
define d value can be sele cted.
1..n, Assignment List
<Name>
1..n, VeEnable
No assig nment,1..n
No assignment 1
<Name>
1..n, Assignment List
Pa rameter of a Module-Input (with
special values): An (1..n) output from the
list will be assigned to the input
"<name>.ide ntifier". If the parameter is
set to "ItemNull", an "inactive"-signal will
be given out.
Limit value monitoring with three
analog input va lues. Compares 3
analog values with the set limit; output
values are three differe nt binary
values as a result of the comparision.
If the analog signal exceeds the limit I/
In, the corresponding output signal
becomes "1".
I/ In
IA
IB
IC
<20%Vn
V
Limit value monitoring (Compared to
a fixed value). Compares a value with
the fixed set limit; output value is
bina ry a s a result of the comparision.
If the signal exceeds the limit, the
corresponding output signal becomes
"1".
Adaptive Parameter
Selection List
<Name>
