Eaton EDR-5000 User Manual

EDR-5000 IM02602007E
Values of the Protection Module
Parameter Description
FaultNo Waveform No.
No of GridFaults Number of grid faults: A grid fault, e.g. a short circuit, might cause several faults with trip and
autoreclosing, each fault being identified by an increased fault number. In this case, the grid fault
number remains the same.
Trip First trip cause which is the same as listed in fault record: See SCADA doc for code (section
Cause of Trip). See manual (section Fault Recorder) for more information.
www.eaton.com 413
