RO-4ZI X Settings
RO-4Z X2
Direct Commands of RO-4ZI X
Parameter Description Setting range Default Menu path
DISARMED This is the second step, after the "DISARMED Ctrl" has
been activated, that is required to DISARM the relay
outputs. This will DISARM those relay outputs that are
currently not latched and that are not timing out.
CAUTION! RELAYS DISARMED in order to safely
perform maintenance while eliminating the risk of taking
an entire process off-line. (Note: Zone Interlocking and
Supervision Contact cannot be disarmed). YOU MUST
ENSURE that the relays are ARMED AGAIN after
maintenance.
Only available if: DISARMED Ctrl = Active
Inactive,
Active
Inactive [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/DISARMED
/RO-4Z X2]
Force all Outs By means of this function the normal Relay Output State
can be overwritten (forced). The relay can be set from
normal operation (relay works according to the assigned
signals) to "force energized" or "force de-energized"
state. Forcing all relay outputs of an entire assembly
group has precedence to forcing a single relay output.
Normal,
De-Energized,
Energized
Normal [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Force RO
/RO-4Z X2]
Force ZI RO Signal: Forced Zone Interlocking OUT Normal,
De-Energized,
Energized
Normal [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Force RO
/RO-4Z X2]
Force RO1 By means of this function the normal Relay Output State
can be overwritten (forced). The relay can be set from
normal operation (relay works according to the assigned
signals) to "force energized" or "force de-energized"
state.
Normal,
De-Energized,
Energized
Normal [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Force RO
/RO-4Z X2]
