1. Two-button Hold Up Alarm with tilt
switch.
2. Two button Hold Up Alarm.
3. Four button remote control.
4. Two-way remote control.
5. Keypad (i-kp01).
6. Keypad (KEY-K01, KEY-KP01 or
KEY-KPZ01)
7. Wireless arming station.
8. Door Contact/Universal Transmitter.
9. Smoke Detector.
10. Passive Infra Red.
11. External siren/strobe.
Figure
1.
Peripherals
A complete i-on16 system comprises a control unit and up to:
16 fixed wireless alarm detectors
One external siren/strobe unit
16 portable four button remote controls
16 portable hold up alarm buttons
16 users.
A
B
1 2 3
5 76
4
8
9 10
11
