Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
34 For more information visit: www.eaton.com
MN04020002E
February 2010
Table 11: All Parameters (continued)
PNU ID
Access
Right
RUN Designation Value Range
Factory
Setting
User
Setting
Digital Input (continued)
P3.3 404 ✓ Start signal [2] like P3.2 2
P3.4 412 ✓ Reversing like P3.2 0
P3.5 405 ✓ External fault
(N/O)
like P3.2 0
P3.6 406 ✓ External fault
(N/C)
like P3.2 0
P3.7 414 ✓ Acknowledge
fault (Reset)
like P3.2 0
P3.8 407 ✓ Start enable like P3.2 5
P3.9 419 ✓ Fixed speed B0 like P3.2 0
P3.10 420 ✓ Fixed speed B1 like P3.2 3
P3.11 421 ✓ Fixed speed B2 like P3.2 4
P3.12 1020 ✓ PI controller,
deactivated
like P3.2 0
P3.13 1400 ✓ Thermistor input like P3.2 6
P3.14 1401 ✓ External brake like P3.2 0
P3.15 1402 ✓ Acceleration /
deceleration time
[2]
like P3.2 0
P3.16 1403 ✓ Inhibit
acceleration/
deceleration
like P3.2 0
P3.17 1404 ✓ Parameters
locked
like P3.2 0
P3.18 1405 ✓
Motor
potentiometer,
increase set point
like P3.2 0
P3.19 1406 ✓ Motor
potentiometer,
reduce set point
like P3.2 0
P3.20 1407 ✓ Motor
potentiometer,
zero set point
like P3.2 0
P3.21 1408 ✓ Program scan,
start
like P3.2 0
P3.22 1409 ✓ Program scan,
pause
like P3.2 0
P3.23 1410 ✓ Counter, trigger
signal
like P3.2 0
P3.24 1411 ✓ Counter, reset like P3.2 0
P3.25 1412 ✓ First/second
source
for control place
like P3.2 0
