50 Eaton Power Xpert 9395 UPS Installation and Operation Manual 164201764—Rev 14

Figure 18. Removing the UPM Section Left Side Shipping Bracket

Shipping Bracket

Bolts

Shipping Bracket

Bolts

Pallet

Left Side Shipping

Bracket

UPM Removable

Front Panels

Wireway Panel

UPS System Installation

Main Page
