SPECIFICATIONS
EATON BladeUPS
®
(12 kVA) User's Guide S 164201649 Rev 4www.eaton.com/powerquality
101
Table 14. Electrical Output
BladeUPS 12 Module BladeUPS 12i Module
Nominal Output Voltage 120/208 Vac three-phase 230/400 Vac three-phase
Output Voltage Variation 104–132 Vac phase to neutral,
180–229 Vac phase to phase
207–253 Vac phase to neutral,
358–438 Vac phase to phase
Connections
IEC 309-60A power cord IEC 309-32A power cord
For paralleling, a single Anderson input/output cord connects to the
BladeUPS Bar (see Table 9 on page 99).
Short Circuit Capability
(Battery Mode)
84A, <300 ms 44A, <300 ms
Short Circuit Capability
(Normal Mode)
Limited by 50A input breaker Limited by 30A input breaker
Nominal Output Frequency 50–60 Hz auto-detection (Normal mode)
50 or 60 Hz (Battery mode)
Output Frequency Variation Synchronized (Normal mode)
±0.1 when not synchronized with source (Battery mode)
Output Overload 100–110%: load transfers to Bypass mode after 10 minutes
110–125%: load transfers to Bypass mode after 1 minute
125–150%: load transfers to Bypass mode after 5 seconds
>150%: load transfers to Bypass mode after 300 ms
Voltage Waveform Normal mode and Battery mode: Sine wave; <2% THD with linear load;
<5% with nonlinear load
Full Output Three-phase
