SPECIFICATIONS
EATON BladeUPS
®
(12 kVA) User's Guide S 164201649 Rev 4www.eaton.com/powerquality
102
Table 15. Environmental and Safety
BladeUPS 12 Module BladeUPS 12i Module
Surge Suppression ANSI C62.41 Category B3 EN 61000-4-6
Safety Conformance UL 1778 4
th
edition; CSA C22.2, No. 107.3 UL 1778 4
th
edition, EN and IEC 62040-1-1
Agency Markings cULus, ICES, CE cULus, GS, CE
EMC (Class A) FCC Part 15 EN 62040-2
Operating Temperature 0°C to 40°C (32°F to 104°F)
Optimal battery performance: 5°C to 25°C (41°F to 77°F)
Storage Temperature 0°C to 25°C (32°F to 77°F)
Transit Temperature -25°C to 55°C (-13°F to 131°F)
Relative Humidity Operating: 5–95% noncondensing
Non-operating: 5–95% relative humidity, 38.7°C (101.7°F)
Maximum wet bulb temperature with no cosmetic damage
Operating Altitude Up to 1,000 meters (3,300 ft) above sea level;
up to 2,000 meters (6,600 ft) with 1% derating per +100 meters (330 ft)
Transit Altitude Up to 15,000 meters (49,000 ft) above sea level
Heat Dissipation 1432 BTU/hr maximum at 100% rated load (High Efficiency mode)
4094 BTU/hr maximum at 100% rated load (Standard mode)
Audible Noise Less than 58 dBA at 1 meter typical (Normal mode)
Less than 64 dBA at 1 meter typical (Battery mode)
Leakage Current <3.5 mA
Communication DB-9: 1200–19200 baud
Table 16. Battery
UPS Internal
Batteries
+1 EBM +2 EBMs +3 EBMs +4 EBMs
Configuration (40) 12V, 5 Ah (20) 12V, 9 Ah (40) 12V, 9 Ah (60) 12V, 9 Ah (80) 12V, 9 Ah
Type Sealed, maintenance‐free, valve‐regulated, lead‐acid
Monitoring Advanced monitoring for earlier failure detection and warning
Charging (in minutes) 8–10 times the discharge time
NOTE Charging times are approximate and are to 80% usable capacity at nominal line voltage after full load discharge.
Table 17. Standalone UPS Battery Runtimes at Full/Half Load (in Minutes)
Model kW
UPS Internal
Batteries
+1 EBM +2 EBMs +3 EBMs +4 EBMs
BladeUPS 12 module 12/6 4.7/13.6 9.5/27 17/42 27/60 34/76
BladeUPS 12i module 12/6 4.7/13.6 9.5/27 17/42 27/60 34/76
NOTE Battery times are approximate and vary depending on the load configuration and battery charge.
