Eaton PVM045 - EATON PVM Piston Pump Service Manual

EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 201710
Parts List
Model PVM045
Model PVM050
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
19
Parts List
Model PVM045
Model PVM050
Item Part No. Qty. Note Description
1 See Table 1 1 Pressure Compensator
2 114953-030 4 A G Soc HD Cap Screw M5
3 104166-011 2 A B G O-Ring
4 104166-017 1 A B G O-Ring
5 See Table 2 1 Drive Shaft
6 See Table 2 1 Key
7 See Table 2 1 Retaining Ring
8 419627 1 E H Bearing S/A
9 See Table 3 1 Valve Plate
10 114997-004 1 Pin (Valve Plate)
11 See Table 4 1 Mounting Flange
12 Not Used Soc HD Cap Screw M5
13 Not Used Soc HD Cap Screw M5
14 932915 1 B Flange Gasket
15 626933 1 B F Shaft Seal
16 101680-175 1 B F Retaining Ring
17 Not Used Seal Collar
18 Not Used Retaining Ring
19 Not Used O-Ring
20 Not Used Filter
21 See Table 5 1 Housing
22 See Table 5 2 O-Ring Plug S/A
23 See Tables 6&7 1 End Cover
24 932916 1 B Gasket
25 Not Used O-Ring Plug S/A
26 See Tables 6&7 2 O-Ring Plug S/A
27 114977-035 8 Soc HD Cap Screw
28 Not Used Soc HD Cap Screw
29 96201-062 4 Roll Pin
30 473914 1 E Bearing S/A
31 4992184-xxx A/R J Spacer
32 934286 1 Control Cap
33 115016-224 1 B O-Ring
34 934287 1 Adjustment Screw
35 4992732-001 1 Jam Nut
36 8770-015 1 B Back-Up Ring
37 104166-015 1 B O-Ring
38 934340 1 Hex Stop
39 932919 1 Control Piston
40 932924 1 B Glide Ring
41 104166-210 1 B O-Ring
42 932920 1 Sleeve
43 114998-028 1 B Back-Up Ring
44 104166-028 1 B O-Ring
45 114998-027 1 B Back-Up Ring
Item Part No. Qty. Note Description
46 104166-027 1 B O-Ring
47 95902-050 1 Pin
48 932921 1 M Chain Link
49 932918 1 Swashplate
50 937055 2 D Cradle Bearing
51 114995-010 2 D Screw Socket Flat Head
52 16026-608 1 D Pin
53 409998 1 D Button
54 934189 1 D Spring Seat
55 932928 1 Inner Bias Spring
56 932929 1 Outer Bias Spring
57 933028 1 C K Cylinder Barrel (045)
57 932930 1 C L Cylinder Barrel (050)
58 101680-162 1 C Retaining Ring
59 423368 1 C Spring Guide, Outer
60 402579 1 C Spring
61 404932 1 C Spring Guide, Inner
62 410050 1 C Pin Retainer
63 114996-006 3 C Pin
64 415621 9 C K Piston Shoe S/A (045)
64 02-328123 9 C L Piston Shoe S/A (050)
65 402650 1 C Shoe Retainer
66 402580 1 C Ballguide
67 Not Used Spacer
68 Not Used Screw
69 See Table 7 1 Adapter
70 114976-025 3 Screw
71 104166-155 1 B O-Ring, Adapter
72 104166-152 1 B O-Ring, End Cover
73 See Table 8 1 Coupling
74 See Table 8 1 Retaining Ring
A Available in control kit. See Table 1.
B Available in seal kit 02-346161.
C Available in rotating group kit 02-346162 for PVM045 or rotating group kit 02-346172 for
PVM050.
D Available in yoke and saddle bearing kit 02-346163.
E Available in shaft bearing kit 02-346164.
F Available in single shaft seal kit 02-346166. Equivalent double shaft seal kit 02-346167.
G Available in control mounting kit 9900104-000.
H Seat bearing cone against shoulder.
J Use spacers to shim as required to obtain 0,01 to 0,10 mm (0.00039 to 0.0039 in.) axial
shaft end play.
K For PVM045 only.
L For PVM050 only.
M Warning: Use Vickers authorized chain link only. Cotter pins on industry standard chain link
will fail.
10
EATON PVM Piston Pump Service Manual
