EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 201712
Parts Tables 1 - 8
Model PVM045
Model PVM050
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
21
Model Code Position
8 12, 13, 14
R S01 934254 115046-006
R S02 932909 115046-006
L S01 934257 115046-006
L S02 934261 115046-006
R S03 934255 115050-022
R S04 934259 115050-022
L S03 934258 115050-022
L S04 934262 115050-022
R E01 934355 115046-006
R E02 934264 115046-006
L E01 934367 115046-006
L E02 934267 115046-006
R E03 934357 115050-022
R E04 934263 115050-022
L E03 934369 115050-022
L E04 934268 115050-022
R S05 934360 4992947-002
R E05 934361 4992947-002
L S05 934373 4992947-002
L E05 934374 4992947-002
Table 6 – End Cover (Non Thru Drive) and Gauge Port Plug
23
Model Code Position
25 Ref
A A9 937238 –
B A11 937236 –
C B13 937237 115015-078
D B15 943792 115015-078
G MA9 937238 –
H MA11 937236 –
J MB13 937237 115015-078
K MB15 943792 115015-078
Table 8 – Coupling (Thru Drive) and Retaining Ring
73 74
26
Model Code Position
8 13, 14 25
R 01 A/B 934301 115046-006 –
R 02 A/B 934238 115046-006 –
R 03 A/B 934359 115050-022 –
R 04 A/B 934269 115050-022 –
R 05 A/B 934363 4992947-002 –
R 03 G/H 934365 115050-022 –
R 04 G/H 934364 115050-022 –
R 05 G/H 934366 4992947-002 –
R 01 C/D 934301 115046-006 934294
R 02 C/D 934238 115046-006 934294
R 03 C/D 934359 115050-022 934294
R 04 C/D 934269 115050-022 934294
R 05 C/D 934363 4992947-002 934294
R 03 J/K 934365 115050-022 934402
R 04 J/K 934364 115050-022 934402
R 05 J/K 934366 4992947-002 934402
L 01 A/B 934370 115046-006 –
L 02 A/B 934271 115046-006 –
L 03 A/B 934372 115050-022 –
L 04 A/B 934272 115050-022 –
L 05 A/B 934375 4992947-002 –
L 03 G/H 934377 115050-022 –
L 04 G/H 934376 115050-022 –
L 05 G/H 934378 4992947-002 –
L 01 C/D 934370 115046-006 934294
L 02 C/D 934271 115046-006 934294
L 03 C/D 934372 115050-022 934294
L 04 C/D 934272 115050-022 934294
L 05 C/D 934375 4992947-002 934294
L 03 J/K 934377 115050-022 934402
L 04 J/K 934376 115050-022 934402
L 05 J/K 934378 4992947-002 934402
Table 7 – End Cover (Thru Drive), Gauge Port Plug and Adapter
23 26 69
Item Torque Values
2 7,4-9 Nm (65-80 in-lb)
22 95-108 Nm (70-80 ft-lb)
26 23-25,8 Nm (17-19 ft-lb)
27 63-77 Nm (46-57 ft-lb)
32 210-230 Nm (155-170 ft-lb)
35 18-24 Nm (13-18 ft-lb)
51 3,6-4,4 Nm (32-39 in-lb)
70 42-50 Nm (31-36,8 ft-lb)
Torque Values
12
EATON PVM Piston Pump Service Manual
