Parts List
Model PVM131
Model PVM141
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
43
Parts List
Model PVM131
Model PVM141
Item Part No. Qty. Note Description
1 See Table 1 1 Pressure Compensator
2 114975-035 4 A G Soc HD Cap Screw M5
3 4992737-111 3 A B G O-Ring
4 Not Used O-Ring
5 See Table 2 1 Drive Shaft
6 See Table 2 1 Key
7 Not Used Retaining Ring
8 388206 1 E H Bearing S/A
9 See Table 3 1 Valve Plate
10 95904-068 1 Pin (Valve Plate)
11 See Table 4 1 Mounting Flange
12 114978-045 4 Soc HD Cap Screw M5
13 114977-060 2 Soc HD Cap Screw M5
14 933088 1 B Flange Gasket
15 864200 1 B F Shaft Seal
16 115019-250 1 B F Retaining Ring
17 934403 1 Seal Collar
18 115018-350 1 B F Retaining Ring
19 104166-152 1 O-Ring
20 882993 Filter
21 See Table 5 1 Housing
22 115046-010 2 O-Ring Plug S/A
23 See Tables 6&7 1 End Cover
24 933087 1 B Gasket
25 Not Used O-Ring Plug S/A
26 115046-006 2 O-Ring Plug S/A
27 114978-065 3 Soc HD Cap Screw
28 114978-100 1 Soc HD Cap Screw
29 96201-062 4 Roll Pin
30 02-328957 1 E Bearing S/A
31 4992187-xxx A/R J Spacer
32 934488 1 Control Cap
33 933080 1 B O-Ring
34 934474 1 Adjustment Screw
35 4992732-002 1 Jam Nut
36 8770-116 1 B Back-Up Ring
37 104166-116 1 B O-Ring
38 934466 1 Hex Stop
39 933049 1 Control Piston
40 933078 1 B Glide Ring
41 104166-123 1 B O-Ring
42 933076 1 Sleeve
43 114998-033 1 B Back-Up Ring
44 104166-033 1 B O-Ring
45 114998-032 1 B Back-Up Ring
Item Part No. Qty. Note Description
46 104166-032 1 B O-Ring
47 95902-050 1 Pin
48 934026 1 M Chain Link
49 933089 1 Swashplate
50 933095 2 D Cradle Bearing
51 114995-010 2 D Screw Socket Flat Head
52 96201-062 1 D Pin
53 933071 1 D Button
54 933081 1 D Spring Seat
55 Not Used Inner Bias Spring
56 933079 1 C Outer Bias Spring
57 933082 1 C K Cylinder Barrel (131)
57 937030 1 C L Cylinder Barrel (141)
58 101680-231 1 C Retaining Ring
59 581104 1 C Spring Guide, Outer
60 626111 1 C Spring
61 417667 1 C Spring Guide, Inner
62 Not Used Pin Retainer
63 Not Used Pin
64 02-159749 9 C K Piston Shoe S/A (131)
64 02-306332 9 C L Piston Shoe S/A (141)
65 683791 1 C K Shoe Retainer (131)
65 928776 1 C L Shoe Retainer (141)
66 526758 2 C Hold Down Straps
67 526757 2 C Spacer
68 114975-030 4 C Screw
69 See Table 7 1 Adapter
70 473800 3 Screw
71 See Table 7 1 B O-Ring, Adapter
72 See Table 7 1 B O-Ring, End Cover
73 See Table 8 1 Coupling
74 Not Used Retaining Ring
A Available in control kit, Table 1.
B Available in seal kit 02-346168.
C Available in rotating group kit 02-346169 for PVM131 or rotating group kit 02-322898 for
PVM141.
D Available in yoke and saddle bearing kit 02-346170.
E Available in shaft bearing kit 02-346171.
F Available in single shaft seal kit 02-346173. Equivalent double shaft seal kit 02-346174.
G Available in control mounting kit 9900105-000.
H Seat bearing cone against shoulder.
J Use to to shim as required to obtain 0,01 to 0,10 mm (0.00039 to 0.0039 in.) axial shaft end
play.
K For PVM131 only.
L For PVM141 only.
M Warning: Use Vickers authorized chain link only. Cotter pins on industry standard chain link
will fail.
