EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 2017 21
Parts Tables 1 - 8
Model PVM074
Model PVM081
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
32
Parts Tables 1 - 8
Model Code Position
13, 14 17, 18, 19 20, 21
All A28 00 02-346262
All A07 00 –
02 B28 11 02-346265
02 B28 24 02-346266
02 C07 24 –
02 C28 11 02-346263
02 C28 24 02-346264
04 B07 11 –
04 B07 24 –
04 B28 11 –
04 B28 24 –
04 C28 11 02-346267
04 C28 24 02-346268
Table 1 – Pressure Compensator
1
Model Code Position
9, 10 25
09 O 943428 –
10 O 943429 –
11 O 943368 –
12 O 943430 –
18 O 943431 4992727-001
19 O 943432 –
09 A-M 943433 –
10 A-M 943434 –
11 A-M 943435 –
12 A-M 943436 –
18 A-M 943437 4992727-001
19 A-M 943438 –
Table 2 – Shaft and Key
5 6
Model Code Position
11 13, 14 15, 16
E 02 00/AA/AC 943396
E 02 AB/AD 943998
E 04 00/AA/AC 943400
E 04 AB/AD 943404
F 04 00/AA/AC 943401
F 04 AB/AD 943405
G 02 00/AA/AC 943352
G 02 AB/AD 943373
G 04 00/AA/AC 943402
G 04 AB/AD 943406
H 04 00/AA/AC 943403
H 04 AB/AD 943407
Table 4 – Mounting Flange
11
Model Code Position
4, 5, 6 7, 8
074 ER 943365
074 MR 943439
074 EL 943440
074 ML 943441
081 ER 943442
081 MR 943443
081 EL 943444
081 ML 943445
Table 3 – Industrial Valve Plate
9
Model Code Position
13, 14
02 943354
04 943412
Table 5 – Housing
21
