EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 201720
Parts List
Model PVM074
Model PVM081
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
31
Parts List
Model PVM074
Model PVM081
Item Part No. Qty. Note Description
1 See Table 1 1 Pressure Compensator
2 114975-035 4 A G Soc HD Cap Screw M5
3 4992737-111 3 A B G O-Ring
4 Not Used 1 O-Ring
5 See Table 2 1 Drive Shaft
6 See Table 2 1 Key
7 Not Used Retaining Ring
8 02-334431 1 E H Bearing S/A
9 See Table 3 1 Valve Plate
10 95904-068 1 Pin (Valve Plate)
11 See Table 4 1 Mounting Flange
12 114977-040 6 Soc HD Cap Screw M5
13 Not Used Soc HD Cap Screw M5
14 943362 1 B Flange Gasket
15 943427 1 B F Shaft Seal
16 101680-225 1 B F Retaining Ring
17 Not Used Seal Collar
18 Not Used Retaining Ring
19 Not Used O-Ring
20 Not Used Filter
21 See Table 5 1 Housing
22 115046-010 2 O-Ring Plug S/A
23 See Tables 6&7 1 End Cover
24 943361 1 B Gasket
25 115046-002 8 O-Ring Plug S/A
26 115046-006 3 O-Ring Plug S/A
27 114978-060 4 Soc HD Cap Screw
28 Not Used 1 Soc HD Cap Screw
29 96201-062 4 Roll Pin
30 02-334424 1 E Bearing S/A
31 4992186-xxx A/R J Spacer
32 943375 1 Control Cap
33 4992737-138 1 B O-Ring
34 943380 1 Adjustment Screw
35 4992732-002 1 Jam Nut
36 8770-015 1 B Back-Up Ring
37 104166-015 1 B O-Ring
38 943381 1 Hex Stop
39 943364 1 Control Piston
40 943367 1 B Glide Ring
41 104166-118 1 B O-Ring
42 943363 1 Sleeve
43 115000-131 1 B Back-Up Ring
44 104166-131 1 B O-Ring
45 115000-129 1 B Back-Up Ring
Item Part No. Qty. Note Description
46 104166-129 1 B O-Ring
47 95902-050 1 Pin
48 943252 1 M Chain Link
49 943356 1 Swashplate
50 943378 2 D Cradle Bearing
51 114995-010 2 D Screw Socket Flat Head
52 96201-062 1 D Pin
53 933071 1 D Button
54 943411 1 D Spring Seat
55 Not Used Inner Bias Spring
56 943366 1 Outer Bias Spring
57 943351 1 C K Cylinder Barrel (074)
57 943376 1 C L Cylinder Barrel (081)
58 101680-193 1 C Retaining Ring
59 631568 1 C Spring Guide, Outer
60 584454 1 C Spring
61 584483 1 C Spring Guide, Inner
62 Not Used Pin Retainer
63 Not Used Pin
64 02-305857 9 C K Piston Shoe S/A (074)
64 02-306364 9 C L Piston Shoe S/A (081)
65 584474 1 C Shoe Retainer
66 690796 2 C Hold Down Straps
67 526639 2 C Spacer
68 114974-025 4 C Screw
69 See Table 7 1 Adapter
70 473800 3 Screw
71 See Table 7 1 B O-Ring, Adapter
72 See Table 7 1 B O-Ring, End Cover
73 See Table 8 1 Coupling
74 Not Used Retaining Ring
A Available in control kit. See Table 1.
B Available in seal kit 9900107-000.
C Available in rotating group kit 877421 for PVM074 or rotating group kit 314746 for PVM081.
D Available in yoke and saddle bearing kit 9900117-000.
E Available in shaft bearing kit 02-334431.
F Available in single shaft seal kit 02-334433. Equivalent double shaft seal kit 02-340717.
G Available in control mounting kit 9900105-000.
H Seat bearing cone against shoulder.
J Use to to shim as required to obtain 0,01 to 0,10 mm (0.00039 to 0.0039 in.) axial shaft end
play.
K For PVM074 only.
L For PVM081 only.
M Warning: Use Vickers authorized chain link only. Cotter pins on industry standard chain link
will fail.
