EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 2017 11
Parts Tables 1 - 8
Model PVM045
Model PVM050
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
20
Parts Tables 1 - 8
Model Code Position
13, 14 17, 18, 19, 20, 21
All A2800 02-345631
All A0700 02-345629
01/02 B2811 02-345594
01/02 C2811 02-345596
01/02 B2824 02-345598
01/02 C2824 02-345600
01/02 B0711 02-345601
01/02 C0711 02-345602
01/02 B0724 02-345603
01/02 C0724 02-345604
03/04 B2811 02-345606
03/04 C2811 02-345608
03/04 B2824 02-345610
03/04 C2824 02-345612
03/04 B0711 02-345613
03/04 C0711 02-345614
03/04 B0724 02-345615
03/04 C0724 02-345616
05 B2811 02-345618
05 C2811 02-345620
05 B2824 02-345622
05 C2824 02-345624
05 B0711 02-345625
05 C0711 02-345626
05 B0724 02-345627
05 C0724 02-345628
Table 1 – Pressure Compensator
1
SAE Port
Metric Port
BSPP Port
Model Code Position
9, 10 11 26
05 C O 934380 22971 –
06 C O 934381 58303 96098-100
07 C O 934382 – –
08 C O 932927 – –
05 C A/B/G/H 934391 22971 –
06 C A/B/G/H 934392 58303 96098-100
07 C A/B/G/H 934393 – –
08 C A/B/G/H 934394 – –
Table 2 – Shaft, Key and Retaining Ring
Model Code Position
11 13, 14 15, 16
C 01/02 00/AA/AC 932914
C 01/02 AB/AD 934397
C 03/04 00/AA/AC 943776
C 03/04 AB/AD 943775
C 05 00/AA/AC 934399
C 05 AB/AD 934400
D 01/02 00/AA/AC 943821
D 01/02 AB/AD 943822
D 03/04 00/AA/AC 943274
D 03/04 AB/AD 934398
D 05 00/AA/AC 943773
D 05 AB/AD 943774
Table 4 – Mounting Flange
11
Model Code Position
4, 5, 6 7, 8
045 ER 932922
045 MR 932925
045 EL 934275
045 ML 934276
050 ER 934280
050 MR 933027
050 EL 934278
050 ML 934277
Table 3 – Industrial Valve Plate
9
Model Code Position
13, 14
02 932912 –
01 932912 –
04 934273 –
03 934273 –
05 934401 49929447-001
Table 5 – Housing and Drain Plugs S/A
21
5 6 7
22
