EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 201716
Parts Tables 1 - 8
Model PVM057
Model PVM063
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
26
Parts Tables 1 - 8
Model Code Position
13, 14 17, 18, 19 20, 21
All A28 00 02-125160
All A07 00 02-125162
01/02 B28 11 02-346306
01/02 B28 24 02-160591
01/02 C07 24 02-306056
01/02 C28 11 02-346305
01/02 C28 24 02-125161
03/04 B07 11 02-347729
03/04 B08 24 02-347728
03/04 B28 11 02-347730
03/04 B28 24 02-347727
03/04 C28 11 02-346307
03/04 C28 24 02-346308
Table 1 – Pressure Compensator
1
Model Code Position
9, 10 11 25
06 C O 937011 4992727-003
07 C O 934574 –
08 C O 937009 –
09 E/G O 937008 114516
11 E/G O 934338 –
17 E/G O 937044 4992727-003
18 E/G O 937050 4992727-001
06 C A to M 937382 –
07 C A to M 937383 –
08 C A to M 937384 –
09 E/G A to M 937380 –
11 E/G A to M 937051 –
17 E/H A to M 939386 –
18 E/H A to M 937385 –
Table 2 – Shaft and Key
5 6
Model Code Position
11 13, 14 15, 16
C 01/02 00/AA/AC 934159
C 01/02 AB/AD 937286
C 03/04 00/AA/AC 937323
C 03/04 AB/AD 937324
D 03/04 00/AA/AC 937287
D 03/04 AB/AD 937288
E 01/02 00/AA/AC 937278
E 01/02 AB/AD 937289
E 03/04 00/AA/AC 937325
E 03/04 AB/AD 937326
F 03/04 00/AA/AC 937290
F 03/04 AB/AD 937291
G 01/02 00/AA/AC 934087
G 01/02 AB/AD 934417
G 03/04 00/AA/AC 937327
G 03/04 AB/AD 937328
H 03/04 00/AA/AC 937001
H 03/04 AB/AD 937002
Table 4 – Mounting Flange
11
Model Code Position
4, 5, 6 7, 8
057 ER 943806
057 MR 943970
057 EL 943971
057 ML 943972
063 ER 943973
063 MR 943974
063 EL 943975
063 ML 943976
Table 3 – Industrial Valve Plate
9
Model Code Position
13, 14
01 934090 115046-010
02 934090 115046-010
03 934599 115050-022
04 934599 115050-022
Table 5 – Housing
21 22
16
