EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 201722
Parts Tables 1 - 8
Model PVM074
Model PVM081
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
33
Model Code Position
8 12, 13, 14
R S02 943358
R S04 943416
L S02 943385
L S04 943423
R E02 943388
R E04 943414
L E02 943383
L E04 943421
Table 6 – End Cover (Non Thru Drive)
23
Model Code Position
8 12, 13, 14 25
R 02 A/B 943391 – – 576601
R 02 C/D 943391 934296 401525 576601
R 02 E/F 943391 934298 353264 576601
R 04 A/B 943418 – – 943809
R 04 C/D 943418 934567 401525 943809
R 04 E/F 943418 934298 353264 943809
R 04 G/H 943419 – – 943809
R 04 J/K 943419 934568 943810 943809
R 04 L/M 943419 934570 943811 943809
L 02 A/B 943393 – – 576601
L 02 C/D 943393 934296 401525 576601
L 02 E/F 943393 934298 353264 576601
L 04 A/B 943425 – – 576601
L 04 C/D 943425 934296 401525 576601
L 04 E/F 943425 934569 353264 576601
L 04 G/H 943426 – – 943809
L 04 J/K 943426 934296 943810 943809
L 04 L/M 943426 934570 943811 943809
Table 7 – End Cover (Thru Drive), Adapter and O-Rings
23 69 71 72
Model Code Position
25 Ref
A A9 864460
B A11 913314
C B13 864457
D B15 864459
E C14 864458
F C17 864461
Table 8 – Coupling
73
Item Torque Values
2 31-37 Nm (23-27.4 ft-lb)
12 103-127 Nm (76.2-94 ft-lb)
22 75-83 Nm (55.5-61.4 ft-lb)
25 15-16 Nm (11.1-11.8 ft-lb)
26 29-32 Nm (21.5-23.7 ft-lb)
27 103-127 Nm (76.2-94 ft-lb)
32 260-300 Nm (192.4-222 ft-lb)
35 18-24 Nm (13.3-17.8 ft-lb)
51 3,6-4.4 Nm (2.7-3.3 ft-lb)
68 12,9-14,9 Nm (9.6-11 ft-lb)
70 103-127 Nm (76.2-94 ft-lb)
Torque Values
22
EATON PVM Piston Pump Service Manual
