EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 2017 7
Parts Tables 1-8
Model PVM018
Model PVM020
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
9
Model Code Position
13, 14
02 943989 115046-008
01 943989 115046-008
04 937164 115050-018
03 937164 115050-018
05 937165 4992947-001
Table 5 – Housing and Port Plugs
21 22
Model Code Position
8 12, 13, 14
R S01 937150
R S02 937435
L S01 937421
L S02 937438
R S03 937151
R S04 937436
L S03 937437
L S04 937439
R E01 937304
R E02 937306
L E01 944173
L E02 937192
R E03 937305
R E04 937307
L E03 937191
L E04 937194
R S05 937052
R E05 937308
L S05 937940
L E05 944170
Table 6 – End Cover (Non Thru Drive)
23
Model Code Position
8 13, 14 25
R 01 A/B 937460
R 02 A/B 937187
R 03 A/B 937461
R 04 A/B 937188
R 05 A/B 937462
R 03 G/H 937463
R 04 G/H 937189
R 05 G/H 937464
L 01 A/B 996816
L 02 A/B 996819
L 03 A/B 996817
L 04 A/B 996820
L 05 A/B 996822
L 03 G/H 996818
L 04 G/H 996821
L 05 G/H 996823
Table 7 – End Cover (Thru Drive)
23
Model Code Position
25 Ref
A A9 937454 101680-062
B A11 937453 101680-062
C B13 – –
D B15 – –
G MA9 937454 101680-062
H MA11 937453 101680-062
J MB13 – –
Table 8 – Coupling (Thru Drive) and Retaining Ring
73 74
Item Torque Values
2 7,4-9 Nm (65-80 in-lb)
22 95-108 Nm (70-80 ft-lb)
25 3.4-4.5 Nm (30.1-39.8 lbf-in)
26 23-25,8 Nm (17-19 ft-lb)
27 63-77 Nm (46-57 ft-lb)
32 210-230 Nm (155-170 ft-lb)
35 18-24 Nm (13-18 ft-lb)
Torque Values
EATON PVM Piston Pump Service Manual
7
