EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 2017 5
Parts List
Model PVM018
Model PVM020
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
7
Parts List
Model PVM018
Model PVM020
Item Part No. Qty. Note Description
1 See Table 1 1 Pressure Compensator
2 114953-030 4 A G Soc HD Cap Screw M5
3 104166-011 2 A B G O-Ring
4 104166-017 1 A B G O-Ring
5 See Table 2 1 Drive Shaft
6 See Table 2 1 Key
7 Not Used Retaining Ring
8 417381 1 E H Bearing S/A
9 See Table 3 1 Valve Plate
10 16028-303 1 Pin (Valve Plate)
11 See Table 4 1 Mounting Flange
12 Not Used Soc HD Cap Screw M5
13 Not Used Soc HD Cap Screw M5
14 943990 1 B Flange Gasket
15 937340 1 B F Shaft Seal
16 101680-162 1 B F Retaining Ring
17 Not Used Seal Collar
18 Not Used Retaining Ring
19 Not Used O-Ring
20 Not Used Filter
21 See Table 5 1 Housing
22 See Table 5 2 O-Ring Plug S/A
23 See Tables 6&7 1 End Cover
24 937317 1 B Gasket
25 115046-002 1 O-Ring Plug S/A
26 115046-004 2 O-Ring Plug S/A
27 114976-040 8 Soc HD Cap Screw
28 Not Used Soc HD Cap Screw
29 16026-608 4 Roll Pin
30 02-335336 1 E Bearing S/A
31 4992182-xxx A/R J Spacer
32 943933 1 Control Cap
33 115016-221 1 B O-Ring
34 997089 1 Adjustment Screw
35 4992732-001 1 Jam Nut
36 8770-015 1 B Back-Up Ring
37 104166-015 1 B O-Ring
38 943934 1 Adjustment Sleeve
39 943931 1 Control Piston
40 937455 1 B Glide Ring
41 104166-110 1 B O-Ring
42 943932 1 Sleeve
43 115001-023 1 B Back-Up Ring
44 104166-023 1 B O-Ring
45 115001-022 1 B Back-Up Ring
Item Part No. Qty. Note Description
46 104166-022 1 B O-Ring
47 16028-303 1 Pin
48 932921 1 M Chain Link
49 943992 1 Swashplate
50 02-340318 2 D Cradle Bearing S/A
51 Not Used Screw Socket Flat Head
52 16026-608 1 D Pin
53 409998 1 D Button
54 409999 1 D Spring Seat
55 Not Used Inner Bias Spring
56 943905 1 Outer Bias Spring
57 937061 1 C Cylinder Barrel (018)
57 937062 1 C K Cylinder Barrel (020)
58 101680-145 1 C L Retaining Ring
59 937338 1 C Spring Guide, Outer
60 937336 1 C Spring
61 937337 1 C Spring Guide, Inner
62 913833 1 C Pin Retainer
63 937339 3 C Pin
64 02-334516 9 C K Piston Shoe S/A (018)
64 02-335670 9 C L Piston Shoe S/A (020)
65 937069 1 C Shoe Retainer
66 937070 1 C Ballguide
67 Not Used Spacer
68 Not Used Screw
69 Not Used Adapter
70 Not Used Screw
71 Not Used O-Ring, Adapter
72 104166-152 1 B O-Ring, End Cover
73 See Table 8 1 Coupling
74 See Table 8 1 Retaining Ring
A Available in control kit. See Table 1.
B Available in seal kit 02-347284.
C Available in rotating group kit 02-347285 for PVM018 or rotating group kit 02-347286 for
PVM020.
D Available in yoke and saddle bearing kit 02-347287.
E Available in shaft bearing kit 02-347288.
F Available in single shaft seal kit 02-347290. Equivalent double shaft seal kit 02-347291.
G Available in control mounting kit 9900104-000.
H Seat bearing cone against shoulder.
J Use spacers to shim as required to obtain 0,01 to 0,10 mm (0.00039 to 0.0039 in.) axial shaft
end play.
K For PVM018 only.
L For PVM020 only.
M Warning: Use Vickers authorized chain link only. Cotter pins on industry standard chain link
will fail.
