EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 2017 15
Parts List
Model PVM057
Model PVM063
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
25
Parts List
Model PVM057
Model PVM063
Item Part No. Qty. Note Description
1 See Table 1 1 Pressure Compensator
2 114975-035 4 A G Soc HD Cap Screw M5
3 4992737-111 3 A B G O-Ring
4 Not Used O-Ring
5 See Table 2 1 Drive Shaft
6 See Table 2 1 Key
7 Not Used Retaining Ring
8 02-334757 1 E H Bearing S/A
9 See Table 3 1 Valve Plate
10 95904-068 1 Pin (Valve Plate)
11 See Table 4 1 Mounting Flange
12 114977-040 4 Soc HD Cap Screw M5
13 Not Used Soc HD Cap Screw M5
14 934445 1 B Flange Gasket
15 513439 1 B F Shaft Seal
16 101680-200 1 B F Retaining Ring
17 934058 Seal Collar
18 101680-300 Retaining Ring
19 104166-040 O-Ring
20 Not Used Filter
21 See Table 5 1 Housing
22 See Table 5 2 O-Ring Plug S/A
23 See Tables 6&7 1 End Cover
24 934444 1 B Gasket
25 16103-104 2 O-Ring Plug S/A
26 115046-006 2 O-Ring Plug S/A
27 114977-045 3 Soc HD Cap Screw
28 114977-090 1 Soc HD Cap Screw
29 96201-062 4 Roll Pin
30 02-328741 1 E Bearing S/A
31 4992188-xxx A/R J Spacer
32 943930 1 Control Cap
33 934580 1 B O-Ring
34 943985 1 Adjustment Screw
35 4992732-002 1 Jam Nut
36 8770-015 1 B Back-Up Ring
37 104166-015 1 B O-Ring
38 937407 1 Hex Stop
39 934052 1 Control Piston
40 934489 1 B Glide Ring
41 104166-211 1 B O-Ring
42 934053 1 Sleeve
43 115000-127 1 B Back-Up Ring
44 104166-127 1 B O-Ring
45 115000-126 1 B Back-Up Ring
Item Part No. Qty. Note Description
46 104166-126 1 B O-Ring
47 16028-303 1 Pin
48 934493 1 M Chain Link
49 934086 1 Swashplate
50 943984 2 D Cradle Bearing
51 114995-010 2 D Screw Socket Flat Head
52 95749-038 1 D Pin
53 409998 1 D Button
54 934429 1 D Spring Seat
55 937489 1 Inner Bias Spring
56 937488 1 Outer Bias Spring
57 934405 1 C K Cylinder Barrel (057)
57 934553 1 C L Cylinder Barrel (063)
58 101680-175 1 C Retaining Ring
59 584524 1 C Spring Guide, Outer
60 627524 1 C Spring
61 680624 1 C Spring Guide, Inner
62 Not Used Pin Retainer
63 Not Used Pin
64 02-306362 9 C K Piston Shoe S/A (057)
64 02-306363 9 C L Piston Shoe S/A (063)
65 584512 1 C K Shoe Retainer (057)
65 860754 1 C L Shoe Retainer (063)
66 690218 2 C Hold Down Straps
67 690801 2 C Spacer
68 114974-025 4 C Screw
69 See Table 7 1 Adapter
70 114977-025 3 Screw
71 See Table 7 1 B O-Ring, Adapter
72 See Table 7 1 B O-Ring, End Cover
73 See Table 8 1 Coupling
74 Not Used Retaining Ring
A Available in control kit. See Table 1.
B Available in seal kit 02-346217.
C Available in rotating group kit 02-346216 for PVM057 or rotating group kit 02-346224 for
PVM063.
D Available in yoke and saddle bearing kit 02-346219.
E Available in shaft bearing kit 02-346220.
F Available in single shaft seal kit 02-346222. Equivalent double shaft seal kit 02-346223.
G Available in control mounting kit 9900105-000.
H Seat bearing cone against shoulder.
J Use spacers to shim as required to obtain 0,01 to 0,10 mm (0.00039 to 0.0039 in.) axial
shaft end play.
K For PVM057 only.
L For PVM063 only.
M Warning: Use Vickers authorized chain link only. Cotter pins on industry standard chain link
will fail.
EATON PVM Piston Pump Service Manual
