Eaton PVM045 - EATON PVM Piston Pump Service Manual

EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 2017 31
Parts Tables 1 - 8
Model PVM131
Model PVM141
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
44
Parts Tables 1 - 8
Model Code Position
13, 14 17, 18, 19 20, 21
All A28 00 02-346262
All A07 00 –
02 B28 11 02-346265
02 B28 24 02-346266
02 C07 24 –
02 C28 11 02-346263
02 C28 24 02-346264
04 B07 11 –
04 B07 24 –
04 B28 11 –
04 B28 24 –
04 C28 11 02-346267
04 C28 24 02-346268
Table 1 – Pressure Compensator
1
Model Code Position
9, 10 11 25
09 E/G O 934463 114516
10 E/G O 934420 140282
11 E/G O 934464 –
12 E/G O 933098 –
13 J O 934462 633260
14 J O 934285 –
18 F/H O 934465 928546
19 F/H O 934467 928547
09 E/G A-F 934469 114516
10 E/G A-F 934471 140282
11 E/G A-F 934470 –
12 E/G A-F 934295 –
13 J A-F 934472 633260
14 J A-F 934321 –
18 F/H A-F 934473 928546
19 F/H A-F 934475 928547
Table 2 – Shaft and Key
5 6
Model Code Position
11 13, 14 15, 16
E 02 00/AA/AC 934520
E 02 AB/AD 934522
F 04 00/AA/AC 934525
F 04 AB/AD 934527
G 02 00/AA/AC 933091
G 02 AB/AD 934404
G 04 00/AA/AC 934558
G 04 AB/AD 934562
H 04 00/AA/AC 934554
H 04 AB/AD 934556
J 02 00/AA/AC 934282
J 02 AB/AD 934571
J 04 00/AA/AC 934560
J 04 AB/AD 934564
K 04 00/AA/AC 934555
K 04 AB/AD 934565
Table 4 – Mounting Flange
11
Model Code Position
4, 5, 6 7, 8
057 ER 937017
057 MR 933083
057 EL 937167
057 ML 937168
063 ER 937169
063 MR 934292
063 EL 937170
063 ML 937171
Table 3 – Industrial Valve Plate
9
Model Code Position
13, 14
02 933093
04 934566
Table 5 – Housing
21
